The gap between tactical mid-range and long-range shooting is now bridged. Enhance your carbine or DMR rifle with a first focal plane optic that's versatile, tough, and ultra-clear at any magnification. Designed for rapid adjustments in fast-changing target scenarios, this optic ensures you stay ahead in every situation.
Magnification | 3-18x |
---|---|
Objective Lens Diameter | 44 mm |
Focal Plane | First Focal Plane |
Reticle | EBR-7C (MOA) |
Turret Style | Exposed Elevation Capped Windage |
Tube Size | 34 mm |
Adjustment Graduation | 1/4 MOA |
Parallax Setting | 10 yds |
Max Windage Adjustment | 62 MOA |
Max Elevation Adjustment | 154 MOA |
Travel Per Rotation | 25 MOA |
Field of View | 39.3' - 6.7' |
Eye Relief | 3.8" |
Length | 13.3" |
Weight | 27.3 oz |
Optical Features | |
---|---|
First Focal Plane Reticle | Scale of reticle remains in proportion to the zoomed image. Constant subtensions allow accurate holdover and ranging at all magnifications. |
XD Optical System | Extra-low dispersion (XD) glass increases resolution and color fidelity, resulting in crisp, sharp images. |
Illuminated Reticle | Provides precise aiming under low-light conditions. |
RevStop™ Zero System | Patented streamlined design offers a toolless zero stop for rock-solid return to zero after turret adjustments. |
Glass-Etched Reticle | Allows for intricate reticle design. Protected between two layers of glass for optimum durability and reliability. |
Fully Multi-Coated Lenses | Anti-reflective coatings on all air-toglass surfaces provide increased light transmission for greather clarity and low-light performance. |
Construction Features | |
---|---|
ArmorTek® | Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt. |
Single-Piece Tube | Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness. |
Aircraft-Grade Aluminum | Constructed from a solid block of aircraft-grade aluminum for strength and rigidity. |
Low Glare Matte Black Annodize | Corrosion and wear resistant anodization provides low-glare matte surface and helps camouflage the shooter's position. |
Nitrogen Gas Purged | Gas purged and O-ring sealed for fogproof and waterproof performance in all conditions. |
Waterproof | Designed to withstand harsh weather conditions |
Fogproof | Nitrogen gas purging prevents internal fogging over a wide range of temperatures |
Shockproof | Designed to withstand the highest levels of recoil and impact. |
Convenience Features | |
---|---|
Fast Focus Eyepiece | Allows quick and easy reticle focusing |
Throw Lever | The included throw lever can be installed for quick and easy magnification adjustments |
