Magnification | 5-30x |
Effective objective lens diameter (mm) | 48.2-50 |
Exit pupil diameter (mm) | 9.5-1.7 |
Exit pupil distance (mm) (Eye relief) | 95 |
Field of view (ft/100 yds / m/100 m) | 23.7-3.9 / 7.9-1.3 |
Field of view (degrees) | 4.5-0.75 |
Field of view, apparent (degrees) | 22.8 |
Dioptric compensation (dpt) | -3 to +2 |
Light transmission (%) | 90 |
Twilight factor acc. to ISO 14132-1 | 14.1-38.7 |
Impact point corr. per click elevation / windage (in/100 yds / mm/100 m) | 0.36/10 / 0.18/5 |
Max. elevation / windage adjustment range (in/100 yds / m/100 m) | 43.2-25.2 / 1.2-0.7 |
Parallax correction (yds / m) | 55-8 / 50-8 |
Objective filter thread | M 52x0.75 |
Length (in / mm) | 15.55 / 395 |
Weight (oz / g) | 21.2 / 600 |
Central tube diameter (in / mm) | 1.18 / 30 |
Functional temperature | -4 °F to +131 °F (-20 °C / +55 °C) |
Storage temperature | -22 °F to +158 °F (-30 °C / +70 °C) |
Submersion tightness | 13 ft / 4 m water depth (inert gas filling) |
