Magnification | 5-25x |
Effective objective lens diameter (mm) | 48-52 |
Exit pupil diameter (mm) | 9.6-2.1 |
Exit pupil distance (mm) (Eye relief) | 95 |
Field of view (ft/100 yds / m/100 m) | 21.9-4.5 / 7.3-1.5 |
Field of view (degrees) | 4.2-0.84 |
Field of view, apparent (degrees) | 21.5 |
Dioptric compensation (dpt) | -3 to +2 |
Light transmission (%) | 90 |
Twilight factor acc. to ISO 14132-1 | 13.2-36 |
Impact point corr. per click (in/100 yds / mm/100 m) | 0.25 / 7 |
Max. elevation / windage adjustment range (in/100 yds / m/100 m) | 43/25 / 1.2/0.7 |
Parallax correction (yds / m) | 55-8 / 50-8 |
Objective filter thread | M 54x0.75 |
Length (in / mm) | 14.61 / 371 |
Weight (oz / g) | 17.5 / 495 |
Central tube diameter (in / mm) | 1 / 25.4 |
Functional temperature | -4 °F to +131 °F (-20 °C / +55 °C) |
Storage temperature | -22 °F to +158 °F (-30 °C / +70 °C) |
Submersion tightness | 13 ft / 4 m water depth (inert gas filling) |
